| PartZenbakia | HV208QX1-100 |
| Marka | HYDIS |
| Tamaina | 20.8 |
| Aplikazio | MD |
| Ebazpena | 2048×1536 |
| Konposizioa | LCM |
| Distira | 800 |
| CR | 700:1 |
| Koloreak | Grayscale |
| Atzeko argia | CCFL |
| Interfazea | LVDS |
| panel marka | BOE HYDIS |
| panel eredua | HV208QX1-100 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 20.8 inch |
| ebazpena | 2048(LCR)×1536 , QXGA |
| bistaratzeko modua | AFFS, Normally Black, Transmissive |
| eremu aktiboa | 423.9×318 mm |
| eskema | 457×350 mm |
| azalera | Antiglare (Haze 13%), Hard coating (3H) |
| distira | 800 cd/m² (Typ.) |
| kontraste-erlazioa | 700:1 (Typ.) |
| bistaratzeko koloreak | Grayscale (8-bit) |
| erantzun denbora | 15/20 (Typ.)(Tr/Td) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 12 pcsCCFLEmbedded (Inverter) |
| seinale interfazea | LVDS (4 ch, 8-bit), 70 pins |
| sarrerako tentsioa | 12.0V (Typ.) |
| aplikazio | MD |
| IAUX61 | IDTech | 19.6 | 1600×1200 |
| ITQX21G | IDTech | 20.8 | 2048×1536 |
| NL160120BM27-03A | NLT | 21.3 | 1600×1200 |
| NL160120BM27-07 | NLT | 21.3 | 1600×1200 |
| NL204153AC21-22 | NLT | 21.3 | 2048×1536 |
| R208RFE-L05 | Innolux | 20.8 | 2048×1536 |
| R213T3-L01 | Innolux | 21.3 | 2560×2048 |
| R300M1-L01 | Innolux | 30.0 | 4096×2560 |
| VVX21F136J00 | Panasonic | 21.3 | 1600×1200 |
| VVX28T143H00 | Panasonic | 28.0 |
