| PartZenbakia | HSD070PFW5-A00 |
| Marka | HannStar |
| Tamaina | 7.0 |
| Aplikazio | Pad & Tablet |
| Ebazpena | 1024×600 |
| Konposizioa | LCM , a-Si TFT-LCD |
| Distira | |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | 3S7P |
| Interfazea | MIPI |
| fabrikatzailea | HannStar |
| ereduaren izena | HSD070PFW5-A00 |
| pantailaren tamaina | 7.0 inch |
| pantaila mota | LCM , a-Si TFT-LCD |
| pixel-zenbakia | 1024(RGB)×600 (WSVGA) 169PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 153.6 × 90 (H×V) |
| eskema (mm) | 161.16 × 100.97 × 5.04 (H×V×D) |
| bezela eremua (mm) | - |
| tratamendua | Hard coating |
| luminantzia | 550 cd/m² (Typ.) |
| kontraste-erlazioa | 1000 : 1 (Typ.) (TM) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| erantzuna | 13/15 (Typ.)(Tr/Td) ms |
| ikuspegi ona | Symmetry |
| lan egiteko modua | IPS Pro, Normally Black, Transmissive |
| kolore-sakonera | 16.7M 50% NTSC |
| atzeko argia | 3S7P WLED , 10K hours , With LED Driver |
| masa | 75.0/85.0g (Typ./Max.) |
| erabiltzen | Pad & Tablet |
| freskatze tasa | 60Hz |
| pantaila taktila | Without |
| seinale mota | MIPI (4 data lanes) , 40 pins Connector |
| tentsio-hornidura | 1.8/3.3/10.7/17/-10V (Typ.)(VDD1/VDD2/AVDD/VGH/VGL) |
| gehienez. balorazioak | Storage Temp.: -20 ~ 65 °C Operating Temp.: -10 ~ 60 °C |
| A070FW03 VD | AUO | 7.0 | 480×234 |
| HJ070IA-04K | Innolux | 7.0 | 800×1280 |
| HSD070PFW1-A00 | HannStar | 7.0 | 1024×600 |
| HSD070PFW3-B02 | HannStar | 7.0 | 1024×600 |
| HSD070PFW3-C01 | HannStar | 7.0 | 1024×600 |
| HSD070PFW3-D00 | HannStar | 7.0 | 1024×600 |
| HSD070PWW1-B01 | HannStar | 7.0 | 1280×800 |
| HSD070PWW1-C00 | HannStar | 7.0 | 1280×800 |
| LB070WV1-TD07 | LG Display | 7.0 | 800×480 |
| LQ070Y5DA02A | SHARP | 7.0 | 800×480 |
