| PartZenbakia | G170EG01 V0 |
| Marka | AUO |
| Tamaina | 17.0 |
| Aplikazio | IA |
| Ebazpena | 1280×1024 |
| Konposizioa | LCM |
| Distira | 380 |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | CCFL |
| Interfazea | LVDS |
| panel marka | AUO |
| panel eredua | G170EG01 V0 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 17.0 inch |
| ebazpena | 1280(RGB)×1024 , SXGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 337.92×270.336 mm |
| eskema | 358.5×296.5×15.8 mm |
| azalera | Antiglare, Hard coating (3H) |
| distira | 380 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (6-bit + Hi-FRC), CIE193172% |
| erantzun denbora | 3.5/1.5 (Typ.)(Tr/Td) |
| ikuspegi angelua | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 4 pcsCCFLWithout Driver |
| seinale interfazea | LVDS (2 ch, 8-bit), 30 pins |
| sarrerako tentsioa | 5.0V (Typ.) |
| aplikazio | IA |
| B170PW02 V0 | AUO | 17.0 | 1440×900 |
| B170PW03 V4 | AUO | 17.0 | 1440×900 |
| B170PW07 V0 | AUO | 17.0 | 1440×900 |
| G170EG01 V0 | AUO | 17.0 | 1280×1024 |
| G170EG01 V1 | AUO | 17.0 | 1280×1024 |
| G170ETN01.0 | AUO | 17.0 | 1280×1024 |
| G170ETN02.0 | AUO | 17.0 | 1280×1024 |
| LM170E03-TLG1 | LG Display | 17.0 | 1280×1024 |
| LTM170E4-P01 | Samsung | 17.0 | 1280×1024 |
| M170EG01 V0 | AUO | 17.0 | 1280×1024 |
| EL320.240.36 IN | Lumineq | 5.7 | 320×240 |
| G190ETN01.2 | AUO | 19.0 | 1280×1024 |
| LB104S01-TL01 | LG Display | 10.4 | 800×600 |
| LM641836R | SHARP | 9.4 | 640×480 |
| LTM08C351L | TOSHIBA | 8.4 | 800×600 |
| NL6448BC26-09C | NLT | 8.4 | 640×480 |
| NL6448BC33-20 | NLT | 10.4 | 640×480 |
| RGS32256064YH001 | RiTdisplay | 3.2 | 256×64 |
| TM084SBHG04 | Tianma | 8.4 | 800×600 |
| UMSH-8377MD-8T | Other | 5.7 | 640×480 |
