| PartZenbakia | G057QTN01.4 |
| Marka | AUO |
| Tamaina | 5.7 |
| Aplikazio | Industrial |
| Ebazpena | 320×240 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 700:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | CMOS |
| panel marka | AUO |
| panelaren tamaina | 5.7" |
| ebazpena | 320(RGB)×240, QVGA, 70PPI |
| bistaratzeko eremua | 115.2(W)×86.4(H) mm |
| distira | 500 cd/m² (Typ.) |
| ikuspegi angelua | 80/80/70/70 (Typ.)(CR≥10) |
| ikuspegirik onena | - |
| bistaratzeko koloreak | 262K |
| maiztasuna | 60Hz |
| panelaren pisua | - |
| seinale interfazea | CMOS (1 ch, 6-bit) |
| ingurunea | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -30 ~ 85 °C |
| panel eredua | G057QTN01.4 |
| panel mota | a-Si TFT-LCD , LCM |
| pixel formatua | RGB Vertical Stripe |
| bezela irekidura | - |
| kontraste-erlazioa | 700:1 (Typ.) (TM) |
| bistaratzeko modua | TN, Normally White, Transmissive |
| erantzun denbora | 15/10 (Typ.)(Tr/Td) |
| lanpara mota | WLED , 75K hours |
| pantaila taktila | Without |
| aplikazio | Industrial |
| AA057VF12 | Mitsubishi | 5.7 | 640×480 |
| CLAA057VC01CW | CPT | 5.7 | 640×480 |
| EL320.240.36 ET CC | Lumineq | 5.7 | 320×240 |
| G057QN01 V0 | AUO | 5.7 | 320×240 |
| G057QN01 V1 | AUO | 5.7 | 320×240 |
| G057QN01 V2 | AUO | 5.7 | 320×240 |
| G057QTN01.1 | AUO | 5.7 | 320×240 |
| KCG057QV1DB-G56 | Kyocera | 5.7 | 320×240 |
| LQ057V3DG02 | SHARP | 5.7 | 640×480 |
| NL6448BC18-06F | NLT | 5.7 | 640×480 |
