| PartZenbakia | EV190E0M-N50 |
| Marka | BOE |
| Tamaina | 19.0 |
| Aplikazio | Medical Imaging |
| Ebazpena | 1280×1024 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 1200:1 |
| Koloreak | Grayscale |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | BOE |
| panel eredua | EV190E0M-N50 |
| panelaren tamaina | 19.0" |
| panel mota | a-Si TFT-LCD, LCM |
| ebazpena | 1280(LCR)×1024, SXGA, 86PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 374.784(W)×299.827(H) mm |
| bezela irekidura | 378.8(W)×303(H) mm |
| eskema tamaina | 396(W)×324(H) ×10.4(D) mm |
| azalera | Antiglare (Haze 25%), Hard coating (3H) |
| distira | 1300 cd/m² (Typ.) |
| kontraste-erlazioa | 1200:1 (Typ.) (TM) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10) |
| bistaratzeko modua | ADS, Normally Black, Transmissive |
| ikuspegirik onena | Symmetry |
| erantzun denbora | 14 (Typ.)(G to G) |
| bistaratzeko koloreak | Grayscale |
| lanpara mota | WLED , 50K hours , Without Driver |
| maiztasuna | 60Hz |
| pantaila taktila | Without |
| panelaren pisua | 1.69Kgs (Typ.) |
| aplikazio | Medical Imaging |
| seinale interfazea | LVDS (2 ch, 8-bit) , 30 pins Connector |
| sarrerako tentsioa | 5.0V (Typ.) |
| ingurunea | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
