| PartZenbakia | ER057005NC6 |
| Marka | EDT |
| Tamaina | 5.7 |
| Aplikazio | IA |
| Ebazpena | 320×240 |
| Konposizioa | LCM |
| Distira | 150 |
| CR | 50:1 |
| Koloreak | Color |
| Atzeko argia | CCFL |
| Interfazea | Parallel Data |
| panel marka | EDT |
| panel eredua | ER057005NC6 |
| panel mota | CSTN-LCD , LCM |
| panelaren tamaina | 5.7 inch |
| ebazpena | 320(RGB)×240 , QVGA |
| bistaratzeko modua | STN, Normally Black, Transmissive |
| eremu aktiboa | 115.2×86.4 mm |
| eskema | 167×109×9.4 mm |
| azalera | |
| distira | 150 cd/m² (Typ.) |
| kontraste-erlazioa | 50:1 (Typ.) |
| bistaratzeko koloreak | Color |
| erantzun denbora | 350/250 (Typ.)(Tr/Td) |
| ikuspegi angelua | 40/40/20/40 (Typ.)(CR≥2)(L/R/U/D) |
| maiztasuna | 120Hz |
| lanpara mota | 1 pcsCCFLWithout Driver |
| seinale interfazea | Parallel Data (8-bit), 16 pins |
| sarrerako tentsioa | 3.3/5.0V (Typ.)(VDD) |
| aplikazio | IA |
