| PartZenbakia | CLAA080WQ08 XN |
| Marka | CPT |
| Tamaina | 8.0 |
| Aplikazio | PAD |
| Ebazpena | 800×1280 |
| Konposizioa | LCM |
| Distira | 400 |
| CR | 900:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| panel marka | CPT |
| panel eredua | CLAA080WQ08 XN |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 8.0 inch |
| ebazpena | 800(RGB)×1280 , WXGA |
| bistaratzeko modua | HFFS, Normally Black, Transmissive |
| eremu aktiboa | 107.64×172.224 mm |
| eskema | 114.6×184.1×4 mm |
| azalera | Antiglare (Haze 25%), Hard coating (3H) |
| distira | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 900:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193153% |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 7S3PWLEDWithout Driver |
| seinale interfazea | MIPI (4 data lanes), 31 pins |
| sarrerako tentsioa | 1.8/3.3V (Typ.)(VDDI/VCCI) |
| aplikazio | PAD |
