| PartZenbakia | CLAA080WK0A XN |
| Marka | CPT |
| Tamaina | 8.0 |
| Aplikazio | Automotive Display |
| Ebazpena | 1280×720 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 900:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | |
| marka | CPT |
| eredua | CLAA080WK0A XN |
| diagonalaren tamaina | 8.0 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 1280(RGB)×720 [WXGA] 183PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 177.024(H)×99.576(V) mm |
| eskema dim. | 182.8(H)×116.9(V) ×6.8(D) mm |
| bezela eremua | 179.024(H)×101.576(V) mm |
| tratamendua | Antiglare (Haze 25%), Hard coating (3H) |
| luminantzia | 600 cd/m² (Typ.) |
| kontraste-erlazioa | 900:1 (Typ.) (TM) |
| ikusi norabidea | Symmetry |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| funtzionamendu modua | HFFS, Normally Black, Transmissive |
| euskarria kolorea | 16.7M 70% NTSC |
| argi iturria | WLED [9S3P] , 50K hours , W/O Driver |
| pisua | 120/230g (Typ./Max.) |
| entzat diseinatua | Automotive Display |
| fotograma-tasa | 60Hz |
| ukipen-panela | Without |
| Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
