| PartZenbakia | CLAA070LQ02 XN |
| Marka | CPT |
| Tamaina | 7.0 |
| Aplikazio | Automotive Display |
| Ebazpena | 800×480 |
| Konposizioa | LCM, a-Si TFT-LCD |
| Distira | |
| CR | 900:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | 7S2P |
| Interfazea | LVDS |
| fabrikatzailea | CPT |
| ereduaren izena | CLAA070LQ02 XN |
| pantailaren tamaina | 7.0 inch |
| pantaila mota | LCM, a-Si TFT-LCD |
| pixel-zenbakia | 800(RGB)×480 (WVGA) 133PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 152.4 × 91.44 (H×V) |
| eskema (mm) | 165 × 104 × 7.3 (H×V×D) |
| bezela eremua (mm) | 154.4 × 93.44 (H×V) |
| tratamendua | Antiglare (Haze 25%) |
| luminantzia | 760 cd/m² (Typ.) |
| kontraste-erlazioa | 900 : 1 (Typ.) (TM) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| erantzuna | 25 (Typ.)(Tr+Tf) ms |
| ikuspegi ona | Symmetry |
| lan egiteko modua | HFFS, Normally Black, Transmissive |
| kolore-sakonera | 262K/16.7M 70% NTSC |
| atzeko argia | 7S2P WLED , 30K hours , No Driver |
| masa | 175g (Typ.) |
| erabiltzen | Automotive Display |
| freskatze tasa | 60Hz |
| pantaila taktila | Without |
| seinale mota | LVDS (1 ch, 6/8-bit) , FPC 60 pins |
| tentsio-hornidura | 3.3/13.0/20.0/-6.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| gehienez. balorazioak | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| CLAA070JA1BCW | CPT | 7.0 | 480×234 |
| CLAA070LC0DCW | CPT | 7.0 | 800×480 |
| CLAA070LC0FCT | CPT | 7.0 | 800×480 |
| CLAA070LF06CW | CPT | 7.0 | 800×480 |
| CLAA070LJ01CW | CPT | 7.0 | 800×480 |
| CLAA070NC0DCT | CPT | 7.0 | 1024×600 |
| CLAA070NJ05CW | CPT | 7.0 | 1024×600 |
| CLAA070WA01 | CPT | 7.0 | 480×234 |
| CLAA070WP03 | CPT | 7.0 | 800×1280 |
| CLAA070WP06G XG | CPT | 7.0 | 800×1280 |
