| PartZenbakia | B116XAK01.2 |
| Marka | AUO |
| Tamaina | 11.6 |
| Aplikazio | Laptop |
| Ebazpena | 1366×768 |
| Konposizioa | LCM , a-Si TFT-LCD |
| Distira | |
| CR | 800:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | eDP |
| fabrikatzailea | AUO |
| pantailaren tamaina | 11.6 inch |
| pixel-zenbakia | 1366(RGB)×768 (WXGA) 135PPI |
| eremu aktiboa (mm) | 256.125 × 144 (H×V) |
| bezela eremua (mm) | - |
| luminantzia | 235 cd/m² (Typ.) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| ikuspegi ona | Symmetry |
| kolore-sakonera | 262K 50% NTSC |
| eskema forma | Slim (PCBA Flat, T≤3.2mm) |
| freskatze tasa | 60Hz |
| seinale mota | eDP (1 Lane) , eDP1.2 , 40 pins Connector |
| tentsio-hornidura | 3.3V (Typ.) |
| gehienez. balorazioak | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 60 °C |
| ereduaren izena | B116XAK01.2 (AUO125C) |
| pantaila mota | LCM , a-Si TFT-LCD |
| antolamendua | RGB Vertical Stripe |
| eskema (mm) | 278 × 168.02 × 3.2 (H×V×D) |
| tratamendua | Antiglare, Hard coating (3H) |
| kontraste-erlazioa | 800 : 1 (Typ.) (TM) |
| erantzuna | 27 (Typ.)(Tr+Tf) ms |
| lan egiteko modua | AHVA, Normally Black, Transmissive |
| atzeko argia | WLED , 15K hours , With LED Driver |
| erabiltzen | Laptop |
| pantaila taktila | On-Cell Touch |
| B116XAN01.0 | AUO | 11.6 | 1366×768 |
| B116XTN02.3 HW0A | AUO | 11.6 | 1366×768 |
| B116XTT01.0 | AUO | 11.6 | 1366×768 |
| B116XTT01.1 | AUO | 11.6 | 1366×768 |
| B116XW01 V0 | AUO | 11.6 | 1366×768 |
| B116XW02 V0 | AUO | 11.6 | 1366×768 |
| B116XW02 V1 | AUO | 11.6 | 1366×768 |
| B116XW03 V1 | AUO | 11.6 | 1366×768 |
| B116XW05 V0 | AUO | 11.6 | 1366×768 |
| B116XW05 V004 | AUO | 11.6 | 1366×768 |
