| PartZenbakia | B080XAN01.0 |
| Marka | AUO |
| Tamaina | 7.9 |
| Aplikazio | PAD |
| Ebazpena | 768×1024 |
| Konposizioa | LCM |
| Distira | 400 |
| CR | 800:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| panel marka | AUO |
| panel eredua | B080XAN01.0 1 Compatible model |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 7.9 inch |
| ebazpena | 768(RGB)×1024 , XGA |
| bistaratzeko modua | AHVA, Normally Black, Transmissive |
| eremu aktiboa | 119.808×159.744 mm |
| azalera | |
| distira | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193150% |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 6 stringsWLEDWithout Driver |
| seinale interfazea | MIPI (4 data lanes), 32 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | PAD |
