| PartZenbakia | B080EAK02.2 |
| Marka | AUO |
| Tamaina | 8.0 |
| Aplikazio | Pad & Tablet |
| Ebazpena | 800×1280 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 900:1 |
| Koloreak | 16.7M |
| Atzeko argia | 4S5P |
| Interfazea | MIPI |
| panel marka | AUO |
| panel eredua | B080EAK02.2 |
| panelaren tamaina | 8.0" |
| panel mota | a-Si TFT-LCD, LCM |
| ebazpena | 800(RGB)×1280, WXGA, 188PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 107.64(W)×172.224(H) mm |
| bezela irekidura | - |
| eskema tamaina | 113.72(W)×183.764(H) ×4.1(D) mm |
| azalera | Glare (Haze 0%) |
| distira | 360 cd/m² (Typ.) |
| kontraste-erlazioa | 900:1 (Typ.) (TM) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| bistaratzeko modua | AHVA, Normally Black, Transmissive |
| ikuspegirik onena | Symmetry |
| erantzun denbora | 25 (Typ.)(Tr+Tf) |
| bistaratzeko koloreak | 16.7M 58% NTSC |
| lanpara mota | 4S5P WLED , 15K hours , Without Driver |
| maiztasuna | 60Hz |
| pantaila taktila | Without |
| panelaren pisua | 120g (Max.) |
| aplikazio | Pad & Tablet |
| seinale interfazea | MIPI (4 data lanes) , 39 pins Connector |
| sarrerako tentsioa | 1.8/3.3V (Typ.)(VCC1/VC2) |
| ingurunea | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| AT080TN03 V.1 | Innolux | 8.0 | 800×480 |
| AT080TN52 V.1 | Innolux | 8.0 | 800×600 |
| B080EAN01.1 | AUO | 8.0 | 800×1280 |
| B080EAN02.0 | AUO | 8.0 | 800×1280 |
| B080EAN02.2 | AUO | 8.0 | 800×1280 |
| C080VW04 V0 | AUO | 8.0 | 800×480 |
| CLAA080MB0DCW | CPT | 8.0 | 800×600 |
| LD080WX2-SMN1 | LG Display | 8.0 | 800×1280 |
| LT080EE04000 | TOSHIBA | 8.0 | 1600×768 |
| TM080TDHG01 | Tianma | 8.0 | 1024×768 |
