| PartZenbakia | AV080WSM-NW2 |
| Marka | BOE |
| Tamaina | 8.0 |
| Aplikazio | Automotive Display |
| Ebazpena | 1024×600 |
| Konposizioa | LCM, a-Si TFT-LCD |
| Distira | |
| CR | 800:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | 3S10P |
| Interfazea | LVDS |
| fabrikatzailea | BOE |
| ereduaren izena | AV080WSM-NW2 |
| pantailaren tamaina | 8.0 inch |
| pantaila mota | LCM, a-Si TFT-LCD |
| pixel-zenbakia | 1024(RGB)×600 (WSVGA) 148PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 176.64 × 99.36 (H×V) |
| eskema (mm) | 192.8 × 116.9 × 4.7 (H×V×D) |
| bezela eremua (mm) | 180.1 × 103.4 (H×V) |
| tratamendua | - |
| luminantzia | 600 cd/m² (Typ.) |
| kontraste-erlazioa | 800 : 1 (Typ.) (TM) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10) |
| erantzuna | 25 (Typ.)(Tr+Td) ms |
| ikuspegi ona | Symmetry |
| lan egiteko modua | ADS, Normally Black, Transmissive |
| kolore-sakonera | 262K/16.7M 50% NTSC |
| atzeko argia | 3S10P WLED , 30K hours , No Driver |
| masa | 176/180g (Typ./Max.) |
| erabiltzen | Automotive Display |
| freskatze tasa | 60Hz |
| pantaila taktila | Without |
| seinale mota | LVDS (1 ch, 6/8-bit) , FPC 40 pins |
| tentsio-hornidura | 3.3/11.5/21/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| gehienez. balorazioak | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
