| PartZenbakia | AM-800600K2TMQW-04H |
| Marka | AMPIRE |
| Tamaina | 10.4 |
| Aplikazio | Industrial |
| Ebazpena | 800×600 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 500:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | AMPIRE |
| panelaren tamaina | 10.4" |
| ebazpena | 800(RGB)×600, SVGA, 96PPI |
| bistaratzeko eremua | 211.2(W)×158.4(H) mm |
| eskema tamaina | 243(W)×185.6(H) mm |
| distira | 500 cd/m² (Typ.) |
| ikuspegi angelua | 70/70/50/60 (Typ.)(CR≥10) |
| ikuspegirik onena | 6 o'clock |
| bistaratzeko koloreak | 262K 50% NTSC |
| maiztasuna | 60Hz |
| panelaren pisua | - |
| seinale interfazea | LVDS (1 ch, 6-bit) , 20 pins Connector |
| sarrerako tentsioa | 3.3V (Typ.) |
| ingurunea | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -35 ~ 85 °C |
| panel eredua | AM-800600K2TMQW-04H |
| panel mota | a-Si TFT-LCD , LCM |
| pixel formatua | RGB Vertical Stripe |
| bezela irekidura | 214.8(W)×162.7(H) mm |
| azalera | - |
| kontraste-erlazioa | 500:1 (Typ.) (TM) |
| bistaratzeko modua | TN, Normally White, Transmissive |
| erantzun denbora | 5/15 (Typ.)(Tr/Td) |
| lanpara mota | WLED , 30K hours , With LED Driver |
| pantaila taktila | Without |
| aplikazio | Industrial |
| AA104VB04 | Mitsubishi | 10.4 | 640×480 |
| AM-800600M3TNQW-00H | AMPIRE | 8.4 | 800×600 |
| AM-800600M3TNQW-01H-F | AMPIRE | 8.4 | 800×600 |
| KCB6448BSTT-X4 | Kyocera | 10.4 | 640×480 |
| LQ10D341 | SHARP | 10.4 | 640×480 |
| LQ10D368 | SHARP | 10.4 | 640×480 |
| NL6448BC33-21 | NLT | 10.4 | 640×480 |
| NL6448BC33-53 | NLT | 10.4 | 640×480 |
| NL8060BC26-15 | NLT | 10.4 | 800×600 |
| TM104SDH02 | Tianma | 10.4 | 800×600 |
