| PartZenbakia | AM-800480BCTMQW-T00H |
| Marka | AMPIRE |
| Tamaina | 5.0 |
| Aplikazio | Industrial |
| Ebazpena | 800×480 |
| Konposizioa | LCM , a-Si TFT-LCD |
| Distira | |
| CR | 600:1 |
| Koloreak | 16.7M |
| Atzeko argia | 6S2P |
| Interfazea | Parallel |
| fabrikatzailea | AMPIRE |
| pantailaren tamaina | 5.0 inch |
| pixel-zenbakia | 800(RGB)×480 (WVGA) 188PPI |
| eremu aktiboa (mm) | 108 × 64.8 (H×V) |
| luminantzia | 340 cd/m² (Typ.) |
| ikuspegi angelua | 75/75/60/70 (Typ.)(CR≥10) |
| ikuspegi ona | 6 o'clock |
| kolore-sakonera | 16.7M 52% NTSC |
| masa | - |
| freskatze tasa | 60Hz |
| seinale mota | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| tentsio-hornidura | 3.3V (Typ.) |
| gehienez. balorazioak | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| ereduaren izena | AM-800480BCTMQW-T00H |
| pantaila mota | LCM , a-Si TFT-LCD |
| antolamendua | RGB Vertical Stripe |
| eskema (mm) | 129.9 × 86.7 × 7.18 (H×V×D) |
| kontraste-erlazioa | 600 : 1 (Typ.) (TM) |
| erantzuna | 4/12 (Typ.)(Tr/Td) ms |
| lan egiteko modua | TN, Normally White, Transmissive |
| atzeko argia | 6S2P WLED , 50K hours , No Driver |
| erabiltzen | Industrial |
| pantaila taktila | PCAP |
| C050FTN01.0 | AUO | 5.0 | 480×234 |
| EJ050NA-01G | Innolux | 5.0 | 800×480 |
| G050VTN01.1 | AUO | 5.0 | 800×480 |
| H495TAN01.1 | AUO | 5.0 | 720×1280 |
| HSD050FMW2-D00 | HannStar | 5.0 | 540×960 |
| HSD050I9W1-A00 | HannStar | 5.0 | 480×272 |
| LM050QC1T01 | SHARP | 5.0 | 320×240 |
| LMS500HF06 | Samsung | 5.0 | 480×272 |
| LQ050A5BS01 | SHARP | 5.0 | 320×234 |
| TM050LDZ00 | Tianma | 5.0 | 240×400 |
