| PartZenbakia | AM-480272MGTZQW-02H |
| Marka | AMPIRE |
| Tamaina | 4.3 |
| Aplikazio | Industrial Outdoor H |
| Ebazpena | 480×272 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | 5S3P |
| Interfazea | Parallel |
| panel marka | AMPIRE |
| panel eredua | AM-480272MGTZQW-02H |
| panelaren tamaina | 4.3" |
| panel mota | a-Si TFT-LCD, LCM |
| ebazpena | 480(RGB)×272, WQVGA, 128PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 95.04(W)×53.856(H) mm |
| bezela irekidura | 97.6(W)×56.0(H) mm |
| eskema tamaina | 105.6(W)×67.2(H) ×3.1(D) mm |
| azalera | - |
| distira | 1000 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) (TM) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| bistaratzeko modua | IPS, Normally Black, Transmissive |
| ikuspegirik onena | Symmetry |
| erantzun denbora | 30 (Typ.)(Tr+Td) |
| bistaratzeko koloreak | 16.7M 51% NTSC |
| lanpara mota | 5S3P WLED , Without Driver |
| maiztasuna | 60Hz |
| pantaila taktila | Without |
| panelaren pisua | - |
| aplikazio | Industrial Outdoor High Brightness Automotive Display |
| seinale interfazea | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| sarrerako tentsioa | 3.3V (Typ.) |
| ingurunea | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
