| PartZenbakia | AM-480272HBTMQW-T00H |
| Marka | AMPIRE |
| Tamaina | 4.3 |
| Aplikazio | Industrial |
| Ebazpena | 480×272 |
| Konposizioa | LCM, a-Si TFT-LCD |
| Distira | |
| CR | 250:1 |
| Koloreak | 16.7M |
| Atzeko argia | 7S1P |
| Interfazea | Parallel |
| fabrikatzailea | AMPIRE |
| ereduaren izena | AM-480272HBTMQW-T00H |
| pantailaren tamaina | 4.3 inch |
| pantaila mota | LCM, a-Si TFT-LCD |
| pixel-zenbakia | 480(RGB)×272 (WQVGA) 128PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 95.04 × 53.856 (H×V) |
| eskema (mm) | 105.5 × 67.2 × 7.99 (H×V×D) |
| bezela eremua (mm) | 98.7 × 57.5 (H×V) |
| tratamendua | - |
| luminantzia | 250 cd/m² (Typ.) |
| kontraste-erlazioa | 250 : 1 (Typ.) (TM) |
| ikuspegi angelua | 65/65/45/45 (Typ.)(CR≥10) |
| erantzuna | 40 (Typ.)(Tr+Td) ms |
| ikuspegi ona | 6 o'clock |
| lan egiteko modua | TN, Normally White, Transmissive |
| kolore-sakonera | 16.7M |
| atzeko argia | 7S1P WLED , 20K hours , No Driver |
| masa | - |
| erabiltzen | Industrial |
| freskatze tasa | 60Hz |
| pantaila taktila | PCAP |
| seinale mota | Parallel RGB (1 ch, 8-bit) , FPC 54 pins |
| tentsio-hornidura | 3.3V (Typ.) |
| gehienez. balorazioak | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| AMS429QC08 | Samsung | 4.3 | 540×960 |
| AT043TN24 V.7 | Innolux | 4.3 | 480×272 |
| BT043NHME601 | BOE | 4.3 | 360×600 |
| LQ043T1DH01 | SHARP | 4.3 | 480×272 |
| LQ043T3DG02 | SHARP | 4.3 | 480×272 |
| LQ043T3DX0A | SHARP | 4.3 | 480×272 |
| LQ043T3DX0G | SHARP | 4.3 | 480×272 |
| LT043MDY5000 | TOSHIBA | 4.3 | 720×1280 |
| TD043MTEA2 | TPO | 4.3 | 800×480 |
| TX11D101VM0EAA | KOE | 4.3 | 480×800 |
