| PartZenbakia | AM-19201200B1TZQW-00-B |
| Marka | AMPIRE |
| Tamaina | 10.1 |
| Aplikazio | Industrial Outdoor H |
| Ebazpena | 1920×1200 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| marka | AMPIRE |
| diagonalaren tamaina | 10.1 inch |
| pixel formatua | 1920(RGB)×1200 [WUXGA] 224PPI |
| eremu aktiboa | 216.806(H)×135.504(V) mm |
| bezela eremua | - |
| luminantzia | 1000 cd/m² (Typ.) |
| ikusi norabidea | Symmetry |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| euskarria kolorea | 16.7M 53% NTSC |
| pisua | - |
| fotograma-tasa | 60Hz |
| interfaze mota | LVDS (2 ch, 8-bit) , 40 pins Connector |
| energia hornidura | 3.3V (Typ.) |
| ingurunea | Operating Temperature: -20 ~ 65 °C ; Storage Temperature: -30 ~ 80 °C |
| eredua | AM-19201200B1TZQW-00-B |
| mota | a-Si TFT-LCD , LCM |
| konfigurazioa | RGB Vertical Stripe |
| eskema dim. | 243.45(H)×155.2(V) ×9.61(D) mm |
| tratamendua | Antiglare |
| kontraste-erlazioa | 800:1 (Typ.) (TM) |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| funtzionamendu modua | Normally Black, Transmissive |
| argi iturria | WLED , 50K hours , With LED Driver |
| entzat diseinatua | Industrial Outdoor High Brightness |
| ukipen-panela | Without |
