| PartZenbakia | AM-1280800W2TZQW-00H |
| Marka | AMPIRE |
| Tamaina | 10.1 |
| Aplikazio | Industrial |
| Ebazpena | 1280×800 |
| Konposizioa | LCM , a-Si TFT-LCD |
| Distira | |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | 7S4P |
| Interfazea | LVDS |
| fabrikatzailea | AMPIRE |
| pantailaren tamaina | 10.1 inch |
| pixel-zenbakia | 1280(RGB)×800 (WXGA) 149PPI |
| eremu aktiboa (mm) | 216.96 × 135.6 (H×V) |
| bezela eremua (mm) | - |
| luminantzia | 1000 cd/m² (Typ.) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| ikuspegi ona | Symmetry |
| kolore-sakonera | 16.7M 44% NTSC |
| masa | 160g (Max.) |
| freskatze tasa | 60Hz |
| seinale mota | LVDS (1 ch, 8-bit) , 40 pins Connector |
| tentsio-hornidura | 3.3V (Typ.) |
| gehienez. balorazioak | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| ereduaren izena | AM-1280800W2TZQW-00H |
| pantaila mota | LCM , a-Si TFT-LCD |
| antolamendua | RGB Vertical Stripe |
| eskema (mm) | 231 × 154.4 × 7.9 (H×V×D) |
| tratamendua | Glare (Haze 0%), Hard coating (3H) |
| kontraste-erlazioa | 800 : 1 (Typ.) (TM) |
| erantzuna | 25 (Typ.)(Tr+Td) ms |
| lan egiteko modua | ADS, Normally Black, Transmissive |
| atzeko argia | 7S4P WLED , 50K hours , No Driver |
| erabiltzen | Industrial |
| pantaila taktila | Without |
