| PartZenbakia | AM-1024768Y2TZQW-A1H |
| Marka | AMPIRE |
| Tamaina | 10.4 |
| Aplikazio | Industrial Outdoor H |
| Ebazpena | 1024×768 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 900:1 |
| Koloreak | 16.2M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | AMPIRE |
| panel eredua | AM-1024768Y2TZQW-A1H |
| panelaren tamaina | 10.4" |
| panel mota | a-Si TFT-LCD, LCM |
| ebazpena | 1024(RGB)×768, XGA, 123PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 211.2(W)×158.4(H) mm |
| bezela irekidura | 213.2(W)×160.4(H) mm |
| eskema tamaina | 236(W)×174.3(H) ×10.4(D) mm |
| azalera | Antiglare, Hard coating (3H) |
| distira | 1000 cd/m² (Typ.) |
| kontraste-erlazioa | 900:1 (Typ.) (TM) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| bistaratzeko modua | IPS, Normally Black, Transmissive |
| ikuspegirik onena | Symmetry |
| erantzun denbora | 30 (Typ.)(Tr+Td) |
| bistaratzeko koloreak | 16.2M |
| lanpara mota | WLED , 30K hours , With LED Driver |
| maiztasuna | 60Hz |
| pantaila taktila | Without |
| panelaren pisua | TBD |
| aplikazio | Industrial Outdoor High Brightness |
| seinale interfazea | LVDS (1 ch, 8-bit) , 20 pins Connector |
| sarrerako tentsioa | 3.3V (Typ.) |
| ingurunea | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| AA104VC04 | Mitsubishi | 10.4 | 640×480 |
| AM-1024768M2TMQW-T00H | AMPIRE | 9.7 | 1024×768 |
| AM-1024768MTMQW-00H | AMPIRE | 10.4 | 1024×768 |
| AM-1024768RTNQW-00H | AMPIRE | 12.0 | 1024×768 |
| G104SN03 V4 | AUO | 10.4 | 800×600 |
| LM10V332R | SHARP | 10.4 | 640×480 |
| LTD104KA1S | TOSHIBA | 10.4 | 1024×768 |
| LTM10C209A | TOSHIBA | 10.4 | 640×480 |
| NL6448BC33-50 | NLT | 10.4 | 640×480 |
| NL6448BC33-63D | NLT | 10.4 | 640×480 |
