| PartZenbakia | AM-1024768V1TZQW-A0H |
| Marka | AMPIRE |
| Tamaina | 8.4 |
| Aplikazio | Industrial |
| Ebazpena | 1024×768 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| marka | AMPIRE |
| eredua | AM-1024768V1TZQW-A0H |
| diagonalaren tamaina | 8.4 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 1024(RGB)×768 [XGA] 152PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 170.8(H)×128.1(V) mm |
| eskema dim. | 203(H)×145.5(V) ×8(D) mm |
| bezela eremua | 174.15(H)×131.2(V) mm |
| tratamendua | - |
| luminantzia | 1000 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) (TM) |
| ikusi norabidea | Symmetry |
| erantzun denbora | 30 (Typ.)(Tr+Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| funtzionamendu modua | IPS, Normally Black, Transmissive |
| euskarria kolorea | 16.7M |
| argi iturria | WLED [6S6P] , 50K hours , With LED Driver |
| pisua | - |
| entzat diseinatua | Industrial |
| fotograma-tasa | 60Hz |
| ukipen-panela | Without |
| interfaze mota | LVDS (1 ch, 8-bit) , 20 pins Connector |
| energia hornidura | 3.3V (Typ.) |
| ingurunea | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 85 °C |
| AA084SD11 | Mitsubishi | 8.4 | 800×600 |
| AM-1024768M2TMQW-T00H | AMPIRE | 9.7 | 1024×768 |
| AM-1024768MTMQW-00H | AMPIRE | 10.4 | 1024×768 |
| AM-1024768RTNQW-00H | AMPIRE | 12.0 | 1024×768 |
| LQ084S3LG03 | SHARP | 8.4 | 800×600 |
| LQ084V1DG21E | SHARP | 8.4 | 640×480 |
| NL6448BC26-08D | NLT | 8.4 | 640×480 |
| NL8060BC21-02 | NLT | 8.4 | 800×600 |
| NL8060BC21-11 | NLT | 8.4 | 800×600 |
| TM084SDHG02 | Tianma | 8.4 | 800×600 |
