| PartZenbakia | AA104XD12 |
| Marka | Mitsubishi |
| Tamaina | 10.4 |
| Aplikazio | IA |
| Ebazpena | 1024×768 |
| Konposizioa | LCM |
| Distira | 1000 |
| CR | 700:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | Mitsubishi |
| panel eredua | AA104XD12 1 Compatible model |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 10.4 inch |
| ebazpena | 1024(RGB)×768 , XGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 210.4×157.8 mm |
| eskema | 230×180.2×11 mm |
| azalera | Antiglare, Hard coating (3H) |
| distira | 1000 cd/m² (Typ.) |
| kontraste-erlazioa | 700:1 (Typ.) |
| bistaratzeko koloreak | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193140% |
| erantzun denbora | 4/12 (Typ.)(Tr/Td) |
| ikuspegi angelua | 80/80/65/65 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 4 stringsWLEDWithout Driver |
| seinale interfazea | LVDS (1 ch, 6/8-bit), 20 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | IA |
| AA104SG01 | Mitsubishi | 10.4 | 800×600 |
| AA104SG04 | Mitsubishi | 10.4 | 800×600 |
| AA104SH02--T1 | Mitsubishi | 10.4 | 800×600 |
| AA104SL02-DE1 | Mitsubishi | 10.4 | 800×600 |
| AA104VC01 | Mitsubishi | 10.4 | 640×480 |
| AA104VC02 | Mitsubishi | 10.4 | 640×480 |
| AA104VH02 | Mitsubishi | 10.4 | 640×480 |
| AA104XD02 | Mitsubishi | 10.4 | 1024×768 |
| AA104XD12 | Mitsubishi | 10.4 | 1024×768 |
| AA104XD12--G1 | Mitsubishi | 10.4 | 1024×768 |
| AA084SD01 | Mitsubishi | 8.4 | 800×600 |
| DLC0560AIG-3 | Other | 5.6 | 640×480 |
| EL320.256-FD6 | Lumineq | 4.8 | 320×256 |
| G057QN01 V0 | AUO | 5.7 | 320×240 |
| G150XG01 V2 | AUO | 15.0 | 1024×768 |
| LQ104S1LG32 | SHARP | 10.4 | 800×600 |
| LQ150X1LGB1 | SHARP | 15.0 | 1024×768 |
| LTA084C274F | TOSHIBA | 8.4 | 800×600 |
| LTD121C33U | TOSHIBA | 12.1 | 800×600 |
| NL12876BC26-28 | NLT | 15.3 | 1280×768 |
