| PartZenbakia | ZV190E0M-N10 |
| Marka | BOE |
| Tamaina | 19.0 |
| Aplikazio | Industrial |
| Ebazpena | 1280×1024 |
| Konposizioa | LCM, a-Si TFT-LCD |
| Distira | |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| fabrikatzailea | BOE |
| ereduaren izena | ZV190E0M-N10 |
| pantailaren tamaina | 19.0 inch |
| pantaila mota | LCM, a-Si TFT-LCD |
| pixel-zenbakia | 1280(RGB)×1024 (SXGA) 86PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 374.784 × 299.827 (H×V) |
| eskema (mm) | 396 × 324 × 13.38 (H×V×D) |
| bezela eremua (mm) | 378.8 × 303 (H×V) |
| tratamendua | - |
| luminantzia | 450 cd/m² (Typ.) |
| kontraste-erlazioa | 1000 : 1 (Typ.) (TM) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10) |
| erantzuna | 14 (Typ.)(G to G) ms |
| ikuspegi ona | Symmetry |
| lan egiteko modua | ADS, Normally Black, Transmissive |
| kolore-sakonera | 16.7M 90% NTSC |
| atzeko argia | WLED , 50K hours , With LED Driver |
| masa | 1.80Kgs (Typ.) |
| erabiltzen | Industrial |
| freskatze tasa | 60Hz |
| pantaila taktila | Without |
| seinale mota | LVDS (2 ch, 8-bit) , Connector 30 pins |
| tentsio-hornidura | 5.0V (Typ.) |
| gehienez. balorazioak | Storage Temp.: -20 ~ 75 °C Operating Temp.: -20 ~ 70 °C |
