| PartZenbakia | WF57STIACDNN0 |
| Marka | Winstar |
| Tamaina | 5.7 |
| Aplikazio | Industrial |
| Ebazpena | 320×240 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 800:1 |
| Koloreak | Grayscale |
| Atzeko argia | WLED |
| Interfazea | 8/16-bit |
| panel marka | Winstar |
| panelaren tamaina | 5.7" |
| ebazpena | 320×240, QVGA, 70PPI |
| bistaratzeko eremua | 115.2(W)×86.4(H) mm |
| eskema tamaina | 160(W)×109(H) ×7.5(D) mm |
| distira | 1000 cd/m² (Typ.) |
| ikuspegi angelua | - |
| ikuspegirik onena | 12 o'clock |
| bistaratzeko koloreak | Grayscale |
| maiztasuna | - |
| panelaren pisua | - |
| seinale interfazea | 8/16-bit 6800/8080 parallel, 3/4-wire SPI , 22 pins FPC |
| sarrerako tentsioa | 3.3V (Typ.) |
| ingurunea | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| panel eredua | WF57STIACDNN0 |
| panel mota | a-Si TFT-LCD , LCM |
| pixel formatua | Rectangle |
| bezela irekidura | 122.0(W)×92.0(H) mm |
| azalera | Glare (Haze 0%) |
| kontraste-erlazioa | 800:1 (Typ.) (TM) |
| bistaratzeko modua | TN, Normally White, Transmissive |
| erantzun denbora | - |
| lanpara mota | WLED , Without Driver |
| pantaila taktila | Without |
| aplikazio | Industrial |
