| PartZenbakia | WF57STIACDNG0 |
| Marka | Winstar |
| Tamaina | 5.7 |
| Aplikazio | Industrial |
| Ebazpena | 320×240 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 800:1 |
| Koloreak | Grayscale |
| Atzeko argia | WLED |
| Interfazea | 8/16-bit |
| marka | Winstar |
| diagonalaren tamaina | 5.7 inch |
| pixel formatua | 320×240 [QVGA] 70PPI |
| eremu aktiboa | 115.2(H)×86.4(V) mm |
| bezela eremua | 117.9(H)×89.1(V) mm |
| luminantzia | 800 cd/m² (Typ.) |
| ikusi norabidea | 12 o'clock |
| ikuspegi angelua | - |
| euskarria kolorea | Grayscale |
| pisua | - |
| fotograma-tasa | - |
| interfaze mota | 8/16-bit 6800/8080 parallel, 3/4-wire SPI , 22 pins FPC |
| energia hornidura | 3.3V (Typ.) |
| ingurunea | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| eredua | WF57STIACDNG0 |
| mota | a-Si TFT-LCD , LCM |
| konfigurazioa | Rectangle |
| eskema dim. | 160(H)×109(V) ×9.24(D) mm |
| tratamendua | Glare (Haze 0%) |
| kontraste-erlazioa | 800:1 (Typ.) (TM) |
| erantzun denbora | - |
| funtzionamendu modua | TN, Normally White, Transmissive |
| argi iturria | WLED , W/O Driver |
| entzat diseinatua | Industrial |
| ukipen-panela | PCAP |
