| PartZenbakia | WEH002002BW |
| Marka | Winstar |
| Tamaina | 5.7 |
| Aplikazio | Instruments & Me |
| Ebazpena | 20×23 |
| Konposizioa | PM-OLED, OLED |
| Distira | |
| CR | |
| Koloreak | Mono(White) |
| Atzeko argia | self |
| Interfazea | CPU/SPI |
| panel marka | Winstar |
| panel eredua | WEH002002BW |
| panelaren tamaina | 5.7" |
| panel mota | PM-OLED, OLED |
| bistaratzeko formatua | 20 characters × 2 lines, 3PPI |
| letra-tipoaren formatua | 5×8 dots |
| karakterearen tamaina | 6×9.66(W×H) mm |
| pertsonaien zelaia | 7.32×10.98(W×H) mm |
| bistaratzeko eremua | 145.08(W)×20.64(H) mm |
| bezela irekidura | 149.0(W)×23.0(H) mm |
| eskema tamaina | 180(W)×40(H) ×9.3(D) mm |
| azalera | - |
| ikuspegi angelua | - |
| bistaratzeko modua | - |
| ikuspegirik onena | Symmetry |
| erantzun denbora | - |
| bistaratzeko koloreak | Mono(White) |
| lanpara mota | self |
| maiztasuna | - |
| pantaila taktila | Without |
| gidariaren ic | COBBuilt-in WS0010 |
| panelaren pisua | - |
| aplikazio | Instruments & Meters |
| seinale interfazea | CPU/SPI , 16 pins Pad |
| sarrerako tentsioa | 5.0V (Typ.) |
