| PartZenbakia | WEH001602DL |
| Marka | Winstar |
| Tamaina | 2.3 |
| Aplikazio | Instruments & Me |
| Ebazpena | 5×8 |
| Konposizioa | OLED, PM-OLED |
| Distira | |
| CR | |
| Koloreak | Mono(Yellow) |
| Atzeko argia | self |
| Interfazea | 8-bit |
| fabrikatzailea | Winstar |
| ereduaren izena | WEH001602DL |
| pantailaren tamaina | 2.3 inch |
| pantaila mota | OLED, PM-OLED |
| kararen zenbakia | 16 characters × 2 lines 7PPI |
| char formatua | 5×8 dots |
| Char-pasa (mm) | 3.6×6.3 (H×V) |
| kararen tamaina (mm) | 2.95×5.55 (H×V) |
| eremu aktiboa (mm) | 56.95 × 11.85 (H×V) |
| eskema (mm) | 85 × 30 × 10 (H×V×D) |
| bezela eremua (mm) | 66 × 16 (H×V) |
| tratamendua | - |
| ikuspegi angelua | - |
| erantzuna | - |
| ikuspegi ona | Symmetry |
| lan egiteko modua | - |
| kolore-sakonera | Mono(Yellow) |
| atzeko argia | self |
| masa | - |
| erabiltzen | Instruments & Meters |
| freskatze tasa | - |
| pantaila taktila | Without |
| gidariaren ic zerrenda | Built-in COB WS0010 |
| seinale mota | 8-bit 6800/8080 parallel , Pad 14 pins |
| tentsio-hornidura | 5.0V (Typ.) |
| AL1602B | Other | 2.3 | 16×2 |
| AMC162A | Other | 2.3 | 16×2 |
| AMC162B | Other | 2.3 | 16×2 |
| DMC-16202NY-LY-BJE-BLN | Kyocera | 2.3 | 16×2 |
| LS023B3UY01 | SHARP | 2.3 | 360×400 |
| TM023KDH60 | Tianma | 2.3 | 320×240 |
