| PartZenbakia | VTF231BJ02 |
| Marka | BOE |
| Tamaina | 23.1 |
| Aplikazio | Digital Signage Stre |
| Ebazpena | 1920×158 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | BOE |
| panel eredua | VTF231BJ02 |
| panelaren tamaina | 23.1" |
| panel mota | a-Si TFT-LCD, LCM |
| ebazpena | 1920×158(RGB), 83PPI |
| pixel formatua | RGB Horizontal Stripe |
| bistaratzeko eremua | 585.216(W)×48.158(H) mm |
| bezela irekidura | 587.5(W)×49.8(H) mm |
| eskema tamaina | 597.2(W)×60.2(H) ×17.1(D) mm |
| azalera | Antiglare (Haze 25%), Hard coating (3H) |
| distira | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) (TM) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| bistaratzeko modua | ADS, Normally Black, Transmissive |
| ikuspegirik onena | Symmetry |
| erantzun denbora | 15 (Typ.)(G to G) |
| bistaratzeko koloreak | 16.7M 72% NTSC |
| lanpara mota | WLED , 30K hours , With LED Driver |
| maiztasuna | 60Hz |
| pantaila taktila | Without |
| panelaren pisua | 450g (Typ.) |
| aplikazio | Digital Signage Stretched Bar LCD |
| seinale interfazea | LVDS (1 ch, 8-bit) , 30 pins Connector |
| sarrerako tentsioa | 12.0V (Typ.) |
| ingurunea | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
