| PartZenbakia | V500HJ1-PE8 Rev.C7 |
| Marka | Chimei Innolux |
| Tamaina | 50 |
| Aplikazio | Transparent Display |
| Ebazpena | 1920×1080 |
| Konposizioa | a-Si TFT-LCD, CELL |
| Distira | |
| CR | 5000:1 |
| Koloreak | 16.7M |
| Atzeko argia | No |
| Interfazea | LVDS |
| marka | Chimei Innolux |
| eredua | V500HJ1-PE8 Rev.C7 |
| diagonalaren tamaina | 50 inch |
| mota | a-Si TFT-LCD, CELL |
| pixel formatua | 1920(RGB)×1080 [FHD] 44PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 1095.84(H)×616.41(V) mm |
| eskema dim. | 1116.38(H)×631.61(V) ×1.31(D) mm |
| bezela eremua | - |
| tratamendua | Antiglare (Haze 1%), Hard coating (3H) |
| luminantzia | 0 cd/m² |
| kontraste-erlazioa | 5000:1 (Typ.) (TM) |
| ikusi norabidea | Symmetry |
| erantzun denbora | 8.5 (Typ.)(G to G) |
| ikuspegi angelua | 88/88/88/88 (Typ.)(CR≥20) |
| funtzionamendu modua | Super MVA, Normally Black, Transmissive |
| plakaren lodiera | - |
| transmisioa | 5.6% (Typ.)(with Polarizer) |
| euskarria kolorea | 16.7M 70% NTSC |
| argi iturria | No B/L |
| pisua | 1.99±0.199Kgs |
| entzat diseinatua | Transparent Display |
| fotograma-tasa | 60Hz |
| ukipen-panela | Without |
| d-ic xehetasuna | COF Built-in 6 source + 4 gate chips |
| interfaze mota | LVDS (2 ch, 8-bit) Connector |
| energia hornidura | 12.0V (Typ.) |
| ingurunea | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| T500HVD01.0 | AUO | 50 | 1920×1080 |
| T500HVN04.5 CELL | AUO | 50 | 1920×1080 |
| T500HVN05.0 CELL | AUO | 50 | 1920×1080 |
| V500DJ2-QS5 | Innolux | 50 | 3840×2160 |
| V500HJ1-L01 | Innolux | 50 | 1920×1080 |
| V500HJ1-ME1 | Innolux | 50 | 1920×1080 |
| V500HJ1-PE6 | Innolux | 50 | 1920×1080 |
| V500HJ1-PE8 | Innolux | 50 | 1920×1080 |
| V500HK1-LE6 | Innolux | 50 | 1920×1080 |
| V500HK2-PS1 | Innolux | 50 | 1920×1080 |
