| PartZenbakia | TX26D89VM2BAA |
| Marka | KOE |
| Tamaina | 10.2 |
| Aplikazio | GM |
| Ebazpena | 800×256 |
| Konposizioa | LCM |
| Distira | 350 |
| CR | 500:1 |
| Koloreak | 262K |
| Atzeko argia | CCFL |
| Interfazea | TTL |
| panel marka | HITACHI |
| panel eredua | TX26D89VM2BAA |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 10.2 inch |
| ebazpena | 800(RGB)×256 , HSVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 246×78.72 mm |
| eskema | 260.2×96.2 mm |
| azalera | |
| distira | 350 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193160% |
| erantzun denbora | 25/10 (Typ.)(Tr/Td) |
| ikuspegi angelua | 50/50/45/50 (Min.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 1 pcsCCFLWithout Driver |
| seinale interfazea | CMOS (1 ch, 6-bit), 40 pins |
| sarrerako tentsioa | 3.3V (Typ.)(VDD) |
| aplikazio | GM |
