| PartZenbakia | TX18D210VM0BAA |
| Marka | KOE |
| Tamaina | 7.0 |
| Aplikazio | Industrial Outdoor H |
| Ebazpena | 800×480 |
| Konposizioa | LCM , LTPS TFT-LCD |
| Distira | |
| CR | 1200:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | Parallel |
| fabrikatzailea | KOE |
| pantailaren tamaina | 7.0 inch |
| pixel-zenbakia | 800(RGB)×480 (WVGA) 133PPI |
| eremu aktiboa (mm) | 152.4 × 91.44 (H×V) |
| bezela eremua (mm) | 156.2 × 94.5 (H×V) |
| luminantzia | 800 cd/m² (Typ.) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| ikuspegi ona | Symmetry |
| kolore-sakonera | 262K 72% NTSC |
| masa | 214g (Typ.) |
| freskatze tasa | 60Hz |
| seinale mota | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| tentsio-hornidura | 3.3V (Typ.) |
| gehienez. balorazioak | Storage Temp.: -40 ~ 90 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 5.0G (49.0 m/s²) |
| ereduaren izena | TX18D210VM0BAA |
| pantaila mota | LCM , LTPS TFT-LCD |
| antolamendua | RGB Vertical Stripe |
| eskema (mm) | 167.7 × 109.5 × 20.3 (H×V×D) |
| tratamendua | - |
| kontraste-erlazioa | 1200 : 1 (Typ.) (TM) |
| erantzuna | 30 (Typ.)(Tr+Td) ms |
| lan egiteko modua | IPS, Normally Black, Transmissive |
| atzeko argia | WLED , 50K hours , With LED Driver |
| erabiltzen | Industrial Outdoor High Brightness Automotive Display |
| pantaila taktila | Without |
