| PartZenbakia | TX17D01VM2EAB |
| Marka | KOE |
| Tamaina | 6.5 |
| Aplikazio | IA |
| Ebazpena | 640×480 |
| Konposizioa | LCM |
| Distira | 1000 |
| CR | 600:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | HITACHI |
| panel eredua | TX17D01VM2EAB |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 6.5 inch |
| ebazpena | 640(RGB)×480 , VGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 132.48×99.36 mm |
| eskema | 153×118 mm |
| azalera | Glare (Haze 0%), Antireflection |
| distira | 1000 cd/m² (Typ.) |
| kontraste-erlazioa | 600:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193150% |
| erantzun denbora | 30 (Typ.)(Tr+Td) |
| ikuspegi angelua | 80/80/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 3S4PWLEDEmbedded (LED Driver) |
| seinale interfazea | CMOS (1 ch, 6-bit), 31 pins |
| sarrerako tentsioa | 3.3V (Typ.)(VDD) |
| aplikazio | IA |
