| PartZenbakia | TV101WXM-NS0 |
| Marka | BOE |
| Tamaina | 10.1 |
| Aplikazio | Pad & Tablet |
| Ebazpena | 1280×800 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 900:1 |
| Koloreak | 16.7M |
| Atzeko argia | 6 |
| Interfazea | LVDS |
| panel marka | BOE |
| panelaren tamaina | 10.1" |
| ebazpena | 1280(RGB)×800, WXGA, 149PPI |
| bistaratzeko eremua | 216.96(W)×135.6(H) mm |
| eskema tamaina | 228.211(W)×148.86(H) ×4.59(D) mm |
| distira | - |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10) |
| ikuspegirik onena | Symmetry |
| bistaratzeko koloreak | 16.7M 50% NTSC |
| maiztasuna | 60Hz |
| panelaren pisua | 130g (Typ.) |
| seinale interfazea | LVDS (1 ch, 8-bit) , 45 pins Connector |
| sarrerako tentsioa | 3.3V (Typ.) |
| ingurunea | Operating Temp.: -20 ~ 65 °C ; Storage Temp.: -40 ~ 80 °C |
| panel eredua | TV101WXM-NS0 |
| panel mota | a-Si TFT-LCD , LCM |
| pixel formatua | RGB Vertical Stripe |
| bezela irekidura | - |
| azalera | Hard coating (2H), Antireflection |
| kontraste-erlazioa | 900:1 (Typ.) (TM) |
| bistaratzeko modua | ADS, Normally Black, Transmissive |
| erantzun denbora | 30 (Typ.)(Tr+Td) |
| lanpara mota | 6 strings WLED , Without Driver |
| pantaila taktila | Without |
| aplikazio | Pad & Tablet |
