| PartZenbakia | TV101WUM-NM1 |
| Marka | BOE |
| Tamaina | 10.1 |
| Aplikazio | Pad & Tablet |
| Ebazpena | 1200×1920 |
| Konposizioa | LCM , a-Si TFT-LCD |
| Distira | |
| CR | 900:1 |
| Koloreak | 16.7M |
| Atzeko argia | 8S4P |
| Interfazea | MIPI |
| fabrikatzailea | BOE |
| ereduaren izena | TV101WUM-NM1 |
| pantailaren tamaina | 10.1 inch |
| pantaila mota | LCM , a-Si TFT-LCD |
| pixel-zenbakia | 1200(RGB)×1920 (WUXGA) 225PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 135.36 × 216.576 (H×V) |
| eskema (mm) | 143 × 227.926 × 4.4 (H×V×D) |
| bezela eremua (mm) | - |
| tratamendua | Antiglare, Hard coating, Antireflection |
| luminantzia | - |
| kontraste-erlazioa | 900 : 1 (Typ.) (TM) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| erantzuna | 30 (Typ.)(Tr+Td) ms |
| ikuspegi ona | Symmetry |
| lan egiteko modua | ADS, Normally Black, Transmissive |
| kolore-sakonera | 16.7M |
| atzeko argia | 8S4P WLED , 30K hours , No Driver |
| masa | 145g (Max.) |
| erabiltzen | Pad & Tablet |
| freskatze tasa | 60Hz |
| pantaila taktila | Without |
| seinale mota | MIPI (4 data lanes) Connector |
| tentsio-hornidura | 3.3V (Typ.)(VDD) |
| gehienez. balorazioak | Storage Temp.: -20 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
| B101AW01 V2 HW5A | AUO | 10.1 | 1024×576 |
| HJ101IA-01F | Innolux | 10.1 | 1280×800 |
| LP101WH4-SLAA | LG Display | 10.1 | 1366×768 |
| LQ101K1LY02 | SHARP | 10.1 | 1280×800 |
| LTL101AL06-002 | Samsung | 10.1 | 1280×800 |
| LTN101NT05-U03 | Samsung | 10.1 | 1024×600 |
| M101NWT2 R0 | IVO | 10.1 | 1024×600 |
| TV101WUM-NH0 | BOE | 10.1 | 1200×1920 |
| TV101WXM-NP0 | BOE | 10.1 | 1280×800 |
| TV101WXM-NP1 | BOE | 10.1 | 1280×800 |
