| PartZenbakia | TV101WUB-NV0 |
| Marka | BOE |
| Tamaina | 10.1 |
| Aplikazio | Pad & Tablet |
| Ebazpena | 1200×1920 |
| Konposizioa | a-Si TFT-LCD, CELL |
| Distira | |
| CR | 900:1 |
| Koloreak | 16.7M |
| Atzeko argia | No |
| Interfazea | MIPI |
| marka | BOE |
| eredua | TV101WUB-NV0 |
| diagonalaren tamaina | 10.1 inch |
| mota | a-Si TFT-LCD, CELL |
| pixel formatua | 1200(RGB)×1920 [WUXGA] 225PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 135.36(H)×216.576(V) mm |
| eskema dim. | 140.26(H)×225.346(V) ×0.8(D) mm |
| luminantzia | 0 cd/m² |
| kontraste-erlazioa | 900:1 (Typ.) (TM) |
| ikusi norabidea | Symmetry |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10) |
| funtzionamendu modua | ADS, Normally Black, Transmissive |
| plakaren lodiera | 0.25+0.25 mm |
| transmisioa | 5.1% (Typ.)(with Polarizer) |
| euskarria kolorea | 16.7M 71% NTSC |
| argi iturria | No B/L |
| pisua | - |
| entzat diseinatua | Pad & Tablet |
| fotograma-tasa | 60Hz |
| ukipen-panela | Without |
| d-ic xehetasuna | COG Built-in 2 source chips |
| interfaze mota | MIPI (4 data lanes) , 44 pins Connector |
| energia hornidura | 3.3/9.8/4.8V (Typ.)(VDDI/AVDD/HAVDD) |
| ingurunea | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
