| PartZenbakia | TM123XDHP90 |
| Marka | TIANMA |
| Tamaina | 12.3 |
| Aplikazio | Industrial Outdoor H |
| Ebazpena | 1920×720 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | 10S4P |
| Interfazea | LVDS |
| panel marka | TIANMA |
| panel eredua | TM123XDHP90 |
| panelaren tamaina | 12.3" |
| panel mota | a-Si TFT-LCD, LCM |
| ebazpena | 1920(RGB)×720, 166PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 292.32(W)×109.62(H) mm |
| bezela irekidura | - |
| eskema tamaina | 311(W)×130(H) ×15.7(D) mm |
| azalera | Antiglare (Haze 28%) |
| distira | 1000 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) (TM) |
| ikuspegi angelua | - |
| bistaratzeko modua | SFT, Normally Black, Transmissive |
| ikuspegirik onena | Symmetry |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| bistaratzeko koloreak | 16.7M 98% sRGB |
| lanpara mota | 10S4P WLED , 10K hours , Without Driver |
| maiztasuna | 60Hz |
| pantaila taktila | Without |
| panelaren pisua | 490g (Typ.) |
| aplikazio | Industrial Outdoor High Brightness Automotive Display |
| seinale interfazea | LVDS (2 ch, 8-bit) , 50 pins FPC |
| sarrerako tentsioa | 3.3V (Typ.) |
| ingurunea | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
