| PartZenbakia | TM123XDHP01 |
| Marka | TIANMA |
| Tamaina | 12.3 |
| Aplikazio | Industrial Automotiv |
| Ebazpena | 1920×720 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | |
| marka | TIANMA |
| diagonalaren tamaina | 12.3 inch |
| pixel formatua | 1920(RGB)×720 166PPI |
| eremu aktiboa | 292.32(H)×109.62(V) mm |
| luminantzia | - |
| ikusi norabidea | Symmetry |
| ikuspegi angelua | - |
| euskarria kolorea | 16.7M sRGB |
| pisua | - |
| fotograma-tasa | 60Hz |
| ingurunea | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C |
| eredua | TM123XDHP01 |
| mota | a-Si TFT-LCD , LCM |
| konfigurazioa | RGB Vertical Stripe |
| eskema dim. | - |
| kontraste-erlazioa | 1000:1 (Typ.) (TM) |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| funtzionamendu modua | SFT, Normally Black, Transmissive |
| argi iturria | WLED |
| entzat diseinatua | Industrial Automotive Display |
| ukipen-panela | Without |
