| PartZenbakia | TM116VDSP03 |
| Marka | TIANMA |
| Tamaina | 11.6 |
| Aplikazio | Industrial Outdoor H |
| Ebazpena | 1920×1080 |
| Konposizioa | LCM , a-Si TFT-LCD |
| Distira | |
| CR | 900:1 |
| Koloreak | 16.7M |
| Atzeko argia | 9S6P |
| Interfazea | LVDS |
| fabrikatzailea | TIANMA |
| ereduaren izena | TM116VDSP03 |
| pantailaren tamaina | 11.6 inch |
| pantaila mota | LCM , a-Si TFT-LCD |
| pixel-zenbakia | 1920(RGB)×1080 (FHD) 190PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 256.32 × 144.18 (H×V) |
| eskema (mm) | 273.5 × 166.5 × 11.5 (H×V×D) |
| bezela eremua (mm) | 259.31 × 148.73 (H×V) |
| tratamendua | Hard coating |
| luminantzia | 1000 cd/m² (Typ.) |
| kontraste-erlazioa | 900 : 1 (Typ.) (TM) |
| ikuspegi angelua | 88/88/88/88 (Typ.)(CR≥10) |
| erantzuna | 25 (Typ.)(Tr+Td) ms |
| ikuspegi ona | Symmetry |
| lan egiteko modua | SFT, Normally Black, Transmissive |
| kolore-sakonera | 16.7M 70% NTSC |
| atzeko argia | 9S6P WLED , 50K hours , No Driver |
| masa | TBD |
| erabiltzen | Industrial Outdoor High Brightness |
| freskatze tasa | 60Hz |
| pantaila taktila | Without |
| seinale mota | LVDS (2 ch, 8-bit) , 30 pins Connector |
| tentsio-hornidura | 3.3/10.7/20/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| gehienez. balorazioak | Storage Temp.: -30 ~ 85 °C Operating Temp.: -20 ~ 70 °C |
