| PartZenbakia | TM103XDKP38-00 |
| Marka | TIANMA |
| Tamaina | 10.3 |
| Aplikazio | Outdoor High Brightn |
| Ebazpena | 1920×720 |
| Konposizioa | LCM, a-Si TFT-LCD |
| Distira | |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | 8S3P |
| Interfazea | LVDS |
| fabrikatzailea | TIANMA |
| ereduaren izena | TM103XDKP38-00 |
| pantailaren tamaina | 10.3 inch |
| pantaila mota | LCM, a-Si TFT-LCD |
| pixel-zenbakia | 1920(RGB)×720 200PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 243.648 × 91.368 (H×V) |
| eskema (mm) | 261.04 × 109.3 (H×V×D) |
| bezela eremua (mm) | - |
| tratamendua | Hard coating, Reflection 5.5% (Typ.) |
| luminantzia | 800 cd/m² (Typ.) |
| kontraste-erlazioa | 1000 : 1 (Typ.) (TM) |
| ikuspegi angelua | 88/88/88/88 (Typ.)(CR≥10) |
| erantzuna | 20 (Typ.)(Tr+Td) ms |
| ikuspegi ona | Symmetry |
| lan egiteko modua | SFT, Normally Black, Transmissive |
| kolore-sakonera | 16.7M 74% NTSC |
| atzeko argia | 8S3P WLED , 10K hours , No Driver |
| masa | TBD |
| erabiltzen | Outdoor High Brightness Automotive Display |
| freskatze tasa | 60Hz |
| pantaila taktila | Without |
| seinale mota | LVDS (2 ch, 8-bit) , Connector 50 pins |
| tentsio-hornidura | 3.3/3.3V (Typ.)(VDD/AVDD) |
| gehienez. balorazioak | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| DJ103FA-01A | Innolux | 10.3 | 1920×720 |
