| PartZenbakia | TM103XDKP05 |
| Marka | TIANMA |
| Tamaina | 10.3 |
| Aplikazio | Outdoor High Brightn |
| Ebazpena | 1920×720 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | |
| marka | TIANMA |
| eredua | TM103XDKP05 |
| diagonalaren tamaina | 10.3 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 1920(RGB)×720 200PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 243.648(H)×91.368(V) mm |
| eskema dim. | 259.84(H)×109.3(V) mm |
| bezela eremua | - |
| tratamendua | Hard coating, Reflection 5.5% (Typ.) |
| luminantzia | 1000 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) (TM) |
| ikusi norabidea | Symmetry |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 88/88/88/88 (Typ.)(CR≥10) |
| funtzionamendu modua | SFT, Normally Black, Transmissive |
| euskarria kolorea | 16.7M 75% NTSC |
| argi iturria | WLED [9S4P] , 10K hours , W/O Driver |
| pisua | 300g (Typ.) |
| entzat diseinatua | Outdoor High Brightness Automotive Display |
| fotograma-tasa | 60Hz |
| ukipen-panela | Without |
| Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| DJ103FA-01A | Innolux | 10.3 | 1920×720 |
