| PartZenbakia | TM097TDHG04-62 |
| Marka | TIANMA |
| Tamaina | 9.7 |
| Aplikazio | Pad & Tablet Industr |
| Ebazpena | 1024×768 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 500:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| marka | TIANMA |
| diagonalaren tamaina | 9.7 inch |
| pixel formatua | 1024(RGB)×768 [XGA] 132PPI |
| eremu aktiboa | 196.608(H)×147.456(V) mm |
| bezela eremua | 200.91(H)×152.27(V) mm |
| luminantzia | 350 cd/m² (Typ.) |
| ikusi norabidea | 12 o'clock |
| ikuspegi angelua | 70/70/60/70 (Typ.)(CR≥10) |
| euskarria kolorea | 262K 50% NTSC |
| pisua | 200g (Typ.) |
| fotograma-tasa | 60Hz |
| interfaze mota | LVDS (1 ch, 6-bit) , 30 pins Connector |
| energia hornidura | 3.3V (Typ.) |
| ingurunea | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| eredua | TM097TDHG04-62 |
| mota | a-Si TFT-LCD , LCM |
| konfigurazioa | RGB Vertical Stripe |
| eskema dim. | 210.2(H)×166.3(V) ×6.5(D) mm |
| tratamendua | Clear |
| kontraste-erlazioa | 500:1 (Typ.) (TM) |
| erantzun denbora | 20/25 (Typ./Max.)(Tr+Td) |
| funtzionamendu modua | TN, Normally White, Transmissive |
| argi iturria | WLED [6S6P] , 30K hours , W/O Driver |
| entzat diseinatua | Pad & Tablet Industrial |
| ukipen-panela | Without |
