| PartZenbakia | TM070RDH10-11 |
| Marka | TIANMA |
| Tamaina | 7.0 |
| Aplikazio | Industrial Digital P |
| Ebazpena | 800×480 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 500:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | 3S8P |
| Interfazea | Parallel |
| panel marka | TIANMA |
| panel eredua | TM070RDH10-11 |
| panelaren tamaina | 7.0" |
| panel mota | a-Si TFT-LCD, LCM |
| ebazpena | 800(RGB)×480, WVGA, 134PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 154.08(W)×85.92(H) mm |
| bezela irekidura | 157.08(W)×89.39(H) mm |
| eskema tamaina | 164.9(W)×100(H) ×6(D) mm |
| azalera | Antiglare |
| distira | 350 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.) (TM) |
| ikuspegi angelua | 70/70/50/70 (Typ.)(CR≥10) |
| bistaratzeko modua | TN, Normally White, Transmissive |
| ikuspegirik onena | 12 o'clock |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| bistaratzeko koloreak | 262K/16.7M 50% NTSC |
| lanpara mota | 3S8P WLED , 20K hours , Without Driver |
| maiztasuna | 60Hz |
| pantaila taktila | Without |
| panelaren pisua | 160g (Typ.) |
| aplikazio | Industrial Digital Photo Frame Portable DVD Player |
| seinale interfazea | Parallel RGB (1 ch, 6/8-bit) , 50 pins FPC |
| sarrerako tentsioa | 3.3/12.5/22.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| ingurunea | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| 70WVW3A | SII | 7.0 | 800×480 |
| BA070WS1-300 | BOE | 7.0 | 1024×600 |
| C070VVN03.3 | AUO | 7.0 | 800×480 |
| CLAA070LC0FCT | CPT | 7.0 | 800×480 |
| TM070RBH10 | Tianma | 7.0 | 800×480 |
| TM070RDH01 | Tianma | 7.0 | 800×480 |
| TM070RDH10 | Tianma | 7.0 | 800×480 |
| TM070RDH11 | Tianma | 7.0 | 800×480 |
| TM070RDH13 | Tianma | 7.0 | 800×480 |
| TX18D40VM1CAA | KOE | 7.0 | 800×480 |
