| PartZenbakia | TM057KDH01-41 |
| Marka | TIANMA |
| Tamaina | 5.7 |
| Aplikazio | Industrial |
| Ebazpena | 320×240 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 500:1 |
| Koloreak | 262K |
| Atzeko argia | 5S3P |
| Interfazea | Parallel |
| panel marka | TIANMA |
| panel eredua | TM057KDH01-41 |
| panelaren tamaina | 5.7" |
| panel mota | a-Si TFT-LCD, LCM |
| ebazpena | 320(RGB)×240, QVGA, 70PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 115.2(W)×86.4(H) mm |
| bezela irekidura | 118.2(W)×89.4(H) mm |
| eskema tamaina | 144(W)×104.6(H) ×12.8(D) mm |
| azalera | Antiglare, Hard coating (3H) |
| distira | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.) (TM) |
| ikuspegi angelua | 70/70/70/60 (Typ.)(CR≥10) |
| bistaratzeko modua | TN, Normally White, Transmissive |
| ikuspegirik onena | 12 o'clock |
| erantzun denbora | 20 (Typ.)(Tr+Td) |
| bistaratzeko koloreak | 262K 50% NTSC |
| lanpara mota | 5S3P WLED , 50K hours , Without Driver |
| maiztasuna | 60Hz |
| pantaila taktila | Without |
| panelaren pisua | 160g (Typ.) |
| aplikazio | Industrial |
| seinale interfazea | Parallel RGB (1 ch, 6-bit) , 33 pins Connector |
| sarrerako tentsioa | 3.3V (Typ.) |
| ingurunea | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| AM-640480GJTNQW-TA0H | AMPIRE | 5.7 | 640×480 |
| ET0570B0DHU | EDT | 5.7 | 640×480 |
| KCS057QV1AJ-G23 | Kyocera | 5.7 | 320×240 |
| KCS057QV1BR-G21 | Kyocera | 5.7 | 320×240 |
| TM057KDH01 | Tianma | 5.7 | 320×240 |
| TM057KDH02 | Tianma | 5.7 | 320×240 |
| TM057KDH03 | Tianma | 5.7 | 320×240 |
| TM057KDH05 | Tianma | 5.7 | 320×240 |
| TM057KDHG03 | Tianma | 5.7 | 320×240 |
| TM057KDHG10 | Tianma | 5.7 | 320×240 |
