| PartZenbakia | TM028HDZG59 |
| Marka | TIANMA |
| Tamaina | 2.8 |
| Aplikazio | Mobile Phone |
| Ebazpena | 240×320 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 400:1 |
| Koloreak | 65K/262K |
| Atzeko argia | WLED |
| Interfazea | 16-bit |
| marka | TIANMA |
| diagonalaren tamaina | 2.8 inch |
| pixel formatua | 240(RGB)×320 [QVGA] 141PPI |
| eremu aktiboa | 43.2(H)×57.6(V) mm |
| luminantzia | 300 cd/m² (Typ.) |
| ikusi norabidea | - |
| ikuspegi angelua | 70/70/70/58 (Typ.)(CR≥10) |
| euskarria kolorea | 65K/262K 63% NTSC |
| pisua | TBD |
| fotograma-tasa | - |
| interfaze mota | 16-bit 8080 parallel , 37 pins FPC |
| energia hornidura | 2.7/3.3V (Min./Max.)(VCI/VCC1/VCC2) |
| ingurunea | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| eredua | TM028HDZG59 |
| mota | a-Si TFT-LCD , LCM |
| konfigurazioa | RGB Vertical Stripe |
| eskema dim. | 50(H)×69.2(V) mm |
| kontraste-erlazioa | 400:1 (Typ.) (TM) |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| funtzionamendu modua | TN, Normally White, Transmissive |
| argi iturria | WLED [1S4P] , W/O Driver |
| entzat diseinatua | Mobile Phone |
| ukipen-panela | Without |
