| PartZenbakia | TCG121XGLPBPNN-AN40-S |
| Marka | Kyocera |
| Tamaina | 12.1 |
| Aplikazio | Industrial Outdoor H |
| Ebazpena | 1024×768 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 600:1 |
| Koloreak | 262K/16.2M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | Kyocera |
| panel eredua | TCG121XGLPBPNN-AN40-S |
| panelaren tamaina | 12.1" |
| panel mota | a-Si TFT-LCD, LCM |
| ebazpena | 1024(RGB)×768, XGA, 105PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 245.76(W)×184.32(H) mm |
| bezela irekidura | 249.0(W)×187.5(H) mm |
| eskema tamaina | 260.5(W)×203(H) ×10.9(D) mm |
| azalera | Antiglare |
| distira | 780 cd/m² (Typ.) |
| kontraste-erlazioa | 600:1 (Typ.) (TM) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| bistaratzeko modua | AWV, Normally Black, Transmissive |
| ikuspegirik onena | Symmetry |
| erantzun denbora | 18/12 (Typ.)(Tr/Td) |
| bistaratzeko koloreak | 262K/16.2M 51% NTSC |
| lanpara mota | WLED , 50K hours , With LED Driver |
| maiztasuna | 60Hz |
| pantaila taktila | Without |
| panelaren pisua | 555g |
| aplikazio | Industrial Outdoor High Brightness |
| seinale interfazea | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| sarrerako tentsioa | 3.3V (Typ.) |
| ingurunea | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C |
