| PartZenbakia | T546HB01 V0 |
| Marka | AUO |
| Tamaina | 55 |
| Aplikazio | LCTV |
| Ebazpena | 1920×1080 |
| Konposizioa | LCM |
| Distira | 360 |
| CR | 4000:1 |
| Koloreak | 16.7M/1.07B |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | AUO |
| panel eredua | T546HB01 V0 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 55 inch |
| ebazpena | 1920(RGB)×1080 , FHD |
| bistaratzeko modua | AMVA3, Normally Black, Transmissive |
| eremu aktiboa | 1209.6×680.4 mm |
| eskema | 1255.6×726.4 mm |
| azalera | |
| distira | 360 cd/m² (Typ.) |
| kontraste-erlazioa | 4000:1 (Typ.) |
| bistaratzeko koloreak | 16.7M/1.07B (8-bit / 8-bit + Hi-FRC), CIE193172% |
| erantzun denbora | 5.5 (Typ.)(G to G) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 120Hz |
| lanpara mota | WLEDEmbedded (LED Driver) |
| seinale interfazea | LVDS (4 ch, 8/10-bit), 92 pins |
| sarrerako tentsioa | 12.0V (Typ.) |
| aplikazio | LCTV |
