| PartZenbakia | T230XW01 V1 |
| Marka | AUO |
| Tamaina | 23.0 |
| Aplikazio | LCTV |
| Ebazpena | 1366×768 |
| Konposizioa | LCM |
| Distira | 450 |
| CR | 700:1 |
| Koloreak | 16.7M |
| Atzeko argia | CCFL |
| Interfazea | LVDS |
| panel marka | AUO |
| panel eredua | T230XW01 V1 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 23.0 inch |
| ebazpena | 1366(RGB)×768 , WXGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 508.152×285.696 mm |
| eskema | 546×318.3 mm |
| azalera | Antiglare, Hard coating (3H) |
| distira | 450 cd/m² (Typ.) |
| kontraste-erlazioa | 700:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (6-bit + Hi-FRC), CIE193172% |
| erantzun denbora | 7/1 (Typ.)(Tr/Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 8 pcsCCFLEmbedded (Inverter) |
| seinale interfazea | LVDS (1 ch, 8-bit), 30 pins |
| sarrerako tentsioa | 5.0V (Typ.) |
| aplikazio | LCTV |
