| PartZenbakia | STCG057QVLAM-G02-S |
| Marka | Kyocera |
| Tamaina | 5.7 |
| Aplikazio | Industrial |
| Ebazpena | 320×240 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 700:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | Parallel |
| marka | Kyocera |
| eredua | STCG057QVLAM-G02-S |
| diagonalaren tamaina | 5.7 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 320(RGB)×240 [QVGA] 70PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 115.2(H)×86.4(V) mm |
| eskema dim. | 144(H)×104.8(V) ×13.5(D) mm |
| bezela eremua | 118.4(H)×89.0(V) mm |
| tratamendua | Glare (Haze 0%) |
| luminantzia | 500 cd/m² (Typ.) |
| kontraste-erlazioa | 700:1 (Typ.) (TM) |
| ikusi norabidea | - |
| erantzun denbora | 10/25 (Typ.)(Tr/Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥5) |
| funtzionamendu modua | TN, Normally White, Transmissive |
| euskarria kolorea | 262K 60% NTSC |
| argi iturria | WLED , 40K hours , W/O Driver |
| pisua | 158g (Typ.) |
| entzat diseinatua | Industrial |
| fotograma-tasa | - |
| ukipen-panela | Without |
| interfaze mota | Parallel RGB (1 ch, 6-bit) , 33 pins Connector |
| energia hornidura | 3.3V (Typ.) |
| ingurunea | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| CLAA057VA02CW | CPT | 5.7 | 640×480 |
| G057QN01 V1 | AUO | 5.7 | 320×240 |
| G057VTN01.1 | AUO | 5.7 | 640×480 |
| KG057QV1CA-G020 | Kyocera | 5.7 | 320×240 |
| LTA057A341F | TOSHIBA | 5.7 | 320×240 |
| MC57T04L | Other | 5.7 | 320×240 |
| PD057VT3 | E Ink | 5.7 | 640×480 |
| PD057VU4 | E Ink | 5.7 | 320×240 |
| TM057KDH03 | Tianma | 5.7 | 320×240 |
| TM057QDHG02 | Tianma | 5.7 | 640×480 |
