| PartZenbakia | ST5461B03-5 |
| Marka | CSOT |
| Tamaina | 55 |
| Aplikazio | TV Sets |
| Ebazpena | 1920×1080 |
| Konposizioa | a-Si TFT-LCD , CELL |
| Distira | |
| CR | 4000:1 |
| Koloreak | 16.7M |
| Atzeko argia | No |
| Interfazea | LVDS |
| marka | CSOT |
| diagonalaren tamaina | 55 inch |
| pixel formatua | 1920(RGB)×1080 [FHD] 40PPI |
| eremu aktiboa | 1209.6(H)×680.4(V) mm |
| bezela eremua | - |
| luminantzia | 0 cd/m² |
| ikusi norabidea | Symmetry |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10) |
| plakaren lodiera | 0.50+0.50 mm |
| euskarria kolorea | 16.7M 72% NTSC |
| pisua | 3.50Kgs (Max.) |
| fotograma-tasa | 60Hz |
| d-ic xehetasuna | COF Built-in 6 source + 8 gate chips |
| interfaze mota | LVDS (2 ch, 8-bit) , 51 pins Connector |
| energia hornidura | 12.0V (Typ.) |
| ingurunea | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| eredua | ST5461B03-5 |
| mota | a-Si TFT-LCD , CELL |
| konfigurazioa | RGB Vertical Stripe |
| eskema dim. | 1223.6(H)×697.1(V) ×1.35(D) mm |
| tratamendua | Antiglare (Haze 2%), Hard coating (3H) |
| kontraste-erlazioa | 4000:1 (Typ.) (TM) |
| erantzun denbora | 7 (Typ.)(G to G) |
| funtzionamendu modua | HVA, Normally Black, Transmissive |
| transmisioa | 6.5% (Typ.)(with Polarizer) |
| argi iturria | No B/L |
| entzat diseinatua | TV Sets |
| ukipen-panela | Without |
