| PartZenbakia | SG8561D01-2 |
| Marka | CSOT |
| Tamaina | 86 |
| Aplikazio | TV Sets |
| Ebazpena | 3840×2160 |
| Konposizioa | a-Si TFT-LCD , CELL |
| Distira | |
| CR | 4000:1 |
| Koloreak | 1.07B |
| Atzeko argia | No |
| Interfazea | V-by-One |
| marka | CSOT |
| diagonalaren tamaina | 86 inch |
| pixel formatua | 3840(RGB)×2160 [UHD] 51PPI |
| eremu aktiboa | 1895.04(H)×1065.96(V) mm |
| bezela eremua | - |
| luminantzia | 0 cd/m² |
| ikusi norabidea | Symmetry |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10) |
| plakaren lodiera | 0.50+0.50 mm |
| euskarria kolorea | 1.07B 99% sRGB |
| pisua | 6.50Kgs (Typ.) |
| fotograma-tasa | 60Hz |
| d-ic xehetasuna | COF Built-in 16 source + 16 gate chips |
| interfaze mota | V-by-One 8 lane , 51 pins Connector |
| energia hornidura | 12.0V (Typ.) |
| ingurunea | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| eredua | SG8561D01-2 |
| mota | a-Si TFT-LCD , CELL |
| konfigurazioa | RGB Vertical Stripe |
| eskema dim. | 1913.04(H)×1083.96(V) ×1.34(D) mm |
| tratamendua | Antiglare (Haze 25%), Hard coating (3H) |
| kontraste-erlazioa | 4000:1 (Typ.) (TM) |
| erantzun denbora | 6.5 (Typ.)(G to G) |
| funtzionamendu modua | HVA, Normally Black, Transmissive |
| transmisioa | 5.5% (Typ.)(with Polarizer) |
| argi iturria | No B/L |
| entzat diseinatua | TV Sets |
| ukipen-panela | Without |
